Perolo Bottom Discharge

Perolo Bottom Discharge

Perolo 3’’ (ND80) Chemfly™ – Bottom Discharge

The Perolo 3′′ CHEMFLYTM bottom discharge valve features a 3′′ CHEMFLY butterfly valve, a 3′′ BSP treaded outlet, and a 3′′ welding neck and is made to fit chemical or food road tankers.

Original Products
Warranty Against Defects
Returns & Refunds Policy
Ships Worldwide
Dedicate Support

Need Help? Call + 971 4 3330105

Email Your Query

Nominal diameter	80 mm (3'')
Weight	8 Kg
Inlet flange	4 holes x Ø14 on a 130 PCD
Outlet flange	3'' BSP
Working pressure	7 bar
Test pressure	10.5 bar
Working temperature	-40° to +150°C
Design temperature	-40° to +190°C

ADR / IMDG / RID / EN14432
Approved by : Bureau veritas

Made of (material)	316L / 1.4409 stainless steel
Angle	180°
Body length	depends on options
O'rings material	Not applicable
Seals material	PTFE
Operating	Locking handle - 1/4 turn
Footvalve spring	Without spring

45° weld-in flange	11 11 59 50 01
PTFE	11 11 59 90 01
Screw kit	11 11 59 99 01
