Grease Closed Hose Reel

Piusi Grease Closed Hose Reel

The Piusi grease hose reel is an automatic closed grease hose reel. It was produced in accordance with the strictest specifications and is appropriate for all heavy-duty grease applications. This reel is made to last because to its sturdy cabinet, which guards against potential harm to the inner parts.

Original Products
Warranty Against Defects
Returns & Refunds Policy
Ships Worldwide
Dedicate Support

Need Help? Call + 971 4 3330105

Email Your Query

Heavy duty spring
Long lasting steal hub
High pressure

Operating Pressure: Max 400 Bar
Hose Length: 12/15m

*PACKAGING*
CODE	WEIGHT		PACKAGING			N.BOXES/ EUROPALLET
CODE	KG	LBS	MM	PCS/PALLET	PCS/BOX
With Hose
HC40123800A	20	44	550X200X540		1	12	20
Without Hose
HNC40151400	14,5	32	550X200X540		1	12	20

Different ways to install PIUSI’s hose reels: they can be easily placed wherever you need them without any problem about functionality and safety. PIUSI’s products are without a doubt designed to support your work in any condition.

Grease hose reel
Wall mount bracket
Instruction manual

Body: Cast Iron
Hub: Synthered Steel
Tube: Rubber

*TECHNICAL DATA*
CODE	DESCRIPTION	FLUIDS TYPE	HOSE	MAX WORKING PRESSURE	PRESSURE DROP	INLET WITH SWIVEL	OUTLET HOSETAIL	HOSE MAX LENGHT BOUND	HOSE LENGHT
CODE	DESCRIPTION	FLUIDS TYPE	BSP	BAR	BAR	BSP	BSP	M	M
*With hose*
HC40123800A	REEL CLOSED 400B W/3/8” 12MT GREASE	RG	3/8”	400	50@600 GR/MIN**	3/8” MALE	3/8” MALE	-	12
*Without hose*
HC40123800A	REEL CLOSED 400B W/3/8” 12MT GREASE	RG	3/8”	400	50@600 GR/MIN**	3/8” MALE	3/8” MALE	-	12
